Single Output Programmable DC Power Supply (0-32V/0-2A)
Description
32V/2A single output programmable DC power supply is used for supplying constant voltage or constant current to an electrical load. It is able to control output stabilized voltage supply through internal program. This DC power source is widely used in schools, researching laboratories and electronic factories.
Advantages
1. 32V/2A single output programmable DC power supply has the advantages of light weight, low noise, high stability, high efficiency, small size and high accuracy.
2. It supports high accuracy and dynamic programming as well as RS232 communication.
Features
32V/2A single output programmable DC power supply is characteristic of CC/CV mode auto switching, high stability, overall output protection and continuously adjustable voltage and current.
Parameters
| Model | LANTYCA-3202D |
| Output Voltage | 0-32.00V (Step 0.01V) |
| Output Current | 0-2.000A |
| Line Regulation | CV≤0.01％+3mV (mA) |
| Load Regulation | CV≤0.01％+3mV (I≤3A) CC≤0.02％+3mV (I≤3A) |
| CV≤0.02％+5mV (I＞3A) CC≤0.02％+5mV (I＞3A) | |
| Noise & Ripple | CV≤1.0mVrms (I≤3A) CC≤3mArms (I≤3A) |
| CV≤2.0mVrms (I＞3A) CC≤6mArms (I＞3A) | |
| Protection Type | OCP |
| Display Resolution | Voltage: ± (0.5％+2 digits) Current: ± (1％+2 digits) |
| Operation Ambient | Temperature: 0-40℃, relative temperature ≤80％ |
| Power Consumption | 77VA |
| Line Voltage | AC220V±10％ 50Hz/60Hz, AC110V±10％ 50Hz/60Hz, |
| Size | 130 (W) × 165 (H) × 330 (D) mm |
| Weight | 4.5 kg |
Notes
1. The instrument should always be in a vertical state without suffering any wind, snow, ice or hail.
2. When there is short circuit in loading equipment, users should stop working immediately and have a check on it.
3. 32V/2A single output programmable DC power supply should be put in good ventilated places. If not, please install a ventilator in the room.
4. When short circuit in loading equipment occurs, please turn off the power to have a check and do not turn it on until short trouble is solved.
Maintenance
1. The most important things are dust prevention and heat dissipation. Besides, do not operate the machine in overload condition.
2. Keep away from gas, steam, chemical deposition, dust, greasy dirt and other explosive or corrosive medium when you install DC stabilized power supply. Then the insulating property of the machine will be well-protected. Try to avoid the action of vibration or turbulence.
3. 32V/2A single output programmable DC power supply should always be in a vertical state without suffering any wind, snow, ice or hail.
4. Please keep regular cleaning in order to maintain good ventilation. Besides, do not spray cleaner directly onto the instrument. Please use a soft cloth with mild detergent and water.
MCH owns a broad market thanks to its excellent service, reliable quality, powerful development strength and strong technical support. Our analog oscilloscope, single output programmable DC power supply (0-32V/0-2A), spectrum analyzer, signal generator and function generator are manufactured according to the global certificates of ISO 9001:2008.
